Top pivot Reversed

Installation in the head jamb or ceiling

This top pivot is slightly different from all the others: Top pivot Reversed can be placed in the head jamb or ceiling. As a result, extra thin door frames can be used because no system needs to be incorporated in the top of the door. For example, you can opt for an extra-large glass opening. Thanks to its placement in the ceiling, this system is not adjusted from the side of the door, but from the ceiling.

Render of a black-framed glass pivot door against a concrete wall with the FritsJurgens top pivot Reversed (TP-R) highlighted in blue, exterior application

Exterior pivot doors

When installing an exterior door, there’s always a head jamb where Top pivot Reversed can be installed in.

Installer fitting the FritsJurgens top pivot Reversed (TP-R) at the top of a black pivot door with a hex key

Easy installing

Thanks to its placement in the head jamb or ceiling, this system is adjusted from the ceiling: convenient for middle placement.

Black steel and glass exterior pivot door at a black timber-clad house with the FritsJurgens top pivot Reversed (TP-R) highlighted in blue

Smaller frames, more glass

With the top pivot installed in the head jamb or ceiling you can design a pivot door with smaller frames and a larger glass opening.

FritsJurgens ceiling plate, stainless steel, product render

Receiver

For Top Pivot Reversed

The receiver is mounted inside the top of the pivot door. The pin of the top pivot Reversed is rotated downwards into the Receiver during the installation

Adapters

The Adapters can be used to mount the components in a metal profile. They then offer a solid base to mount the component on.

FritsJurgens top pivot Reversed (TP-R), stainless steel, product render

Top pivot Reversed cable entry

The top pivot reversed is equipped with cable entry as standard and is suitable for doors between 20 kg and 500 kg.

Cover plates

FritsJurgens’ TP-R is mounted inside the head jamb or ceiling. This means the top pivot is visible instead of a ceiling plate, as with other FritsJurgens top pivots. When the top pivot has been mounted, and the door has been fine-tuned, a magnetic cover plate is attached to the visible part of the top pivot. This cover plate is included in the order and is available in Stainless Steel, PVD Black, and Powder Coat White (RAL9016).
