System 3

System 3 is a 360° rotating pivot system with various hold positions, ideal for pivoting walls.


System 3 in one minute

Flexibility all around

360° rotation

System 3 offers rotation all around, while maintaining features like self-closure and hold positions.

Assisted closure and hold positions

From every 45° angle, System 3 rotates automatically towards its hold positions at 0°, 90°, 180° or 270°.


Pivoting walls

360° rotation combined with hold positions and self-closure are ideal features for pivoting walls.

Take a look at System 3

Drag over the photos for more

Components

A pivot door needs various components – the pivot system, a floor plate, a ceiling plate, and a top pivot.

Click a component
close

Ceiling plates

The ceiling plate is fitted in the ceiling, where the pin of the top pivot seamlessly fits into the hole in the ceiling plate. The ceiling plate is available in two finishes: brushed stainless steel and black.

Top pivot

The top pivot is mounted into the top of the door. It uses a so-called pinhole connection, in which the pin is fixed to the top pivot and goes into the hole in the ceiling plate when the door is placed.

Floor plates

Every FritsJurgens floor plate is mounted 8 mm in the floor. This is sufficient for almost every floor type and makes it possible to combine FritsJurgens’ hinges with floor heating.

There are two floor plate designs available for System 3. You can choose for a round floor plate or a square floor plate in brushed stainless steel (Series 420). The floor plates by FritsJurgens are made of solid tempered steel and, therefore, entirely scratch resistant.

Bottom pivot

The bottom pivot is the pivot mechanism and driver of the pivot door and is fitted in the bottom side of the door. The pivot mechanism therefore is virtually invisible. FritsJurgens bottom pivots have a load bearing capacity for pivot doors up to 500 Kg.

The bottom pivot offers several features, depending on the choice of bottom pivot, such as: hold positions, self-closing, damper control, latch control, 30° speed control, free swing.

The bottom pivots placement determines the the spatial impact that thepivot door will have on its surroundings. Besides a more regular side placement to create pivot doors, FritsJurgens pivot hinges are also suitable for 360 degree rotating panels or walls.

What is the right type for you?


System 3 comes in 4 different types, all specifically designed for your pivot door weight and dimensions. Find out which type you should order for your pivot door.

Smart installation


All of FritsJurgens’ pivot hinges can be milled and installed quickly and easily. On-site, installation takes only around 30 minutes.

Both in new and retrofit situations, the installation is done in four steps: mounting the floor plate, mounting the ceiling plate, installing the door, and fine-tuning the door.

Technical specifications

System specifications
Types System 3 - AA
System 3 - C
System 3 - E
System 3 - G
Dimensions 160 x 32 x 143 mm
Weight 0,75 KG
Material Stainless Steel | Anodized aluminum
Corrosion resistance EN 1670 - class 5 (norm:0-5)
Door specifications
Door acting Double-acting | 360º rotation
Hold positioning Hold positions 0º, 90º, 180º and 270º
Weight capacity 40 - 350 kg
Door width 1000 - 3800 mm
Door height Unlimited
Pivot point Middle
Min. door thickness 40 mm
Top gap 4-10 mm
Bottom gap 13 mm
Door movement Door moves from each 45º angle, in both directions, to a hold position.

Downloads

2D drawing System 3
DWG File, 553.21 KB
3D drawing System 3 (STEP)
STEP File, 866.89 KB
Milling & mounting manual System One (previous model)/3
PDF File, 2.68 MB
Specification Text
RTF File, 2.08 KB

Frequently asked questions

How do I choose the right type?
To select the right type of System 3 for your pivot door, use the FritsJurgens Selector.
How do I know if System 3 is the right choice for my pivot door?
To find out if System 3 is the right choice for your door design, use the FritsJurgens Selector.

Accessories

To optimize the installation and functionality of your pivot door, FritsJurgens offers various accessories. You can add these accessories to your order, which you can configure through the FritsJurgens Selector.
